| HEAD TYPE |
Flange |
| FLANGE MATERIAL |
Brass / Stainless steel |
| FLANGE DIAMETER |
From 48 mm to 92 mm, according to Customer specification |
| ELEMENT MATERIAL |
Copper / Stainless steel (AISI) / High grade nickel alloy (INCOLOY) / Titanium |
| ELEMENT DIAMETER |
85 mm |
| ELEMENT SHAPE AND DIMENSION |
According to Customer specification |
| RATED VOLTAGE |
Up to 240 V single-phase or up to 480 V three-phase, according to Customer specification |
| RATED POWER |
According to Customer specification |
| SURFACE LOAD |
Up to 20 W/cm^2 |
| THERMOSTAT AND SENSOR POCKET MATERIAL |
Copper / Stainless steel (AISI) / High grade nickel alloy (INCOLOY) / Titanium |
| THERMOSTAT AND SENSOR POCKET DIAMETER |
From 8 mm to 12 mm, according to Customer specification |
| THERMOSTAT AND SENSOR POCKET LENGHT |
According to Customer specification |
| ELECTRICAL CONNECTION |
Faston terminals / Screw terminals, according to Customer specification |
| ANODE CONNECTION |
With (M5, M6 or M8 thread) / Without |
